8MP IMX415 Black Light Full-Color AI Camera Module – SSC338Q Smart Vision Board for 24/7 Surveillance
Overview
Experience crystal-clear imaging even in near-total darkness with the MC800S 8MP Black Light Camera Module – a high-performance, AI-powered vision solution built around the Sony IMX415 1/2.8″ CMOS sensor and the advanced SSC338Q intelligent processor. Designed for demanding security, industrial IoT, and smart city applications, this compact (38×38mm) module delivers true full-color night vision, dual-light illumination, and edge-based human detection—without compromising reliability or integration flexibility.
Key Features
Ultra-Low-Light Full-Color Imaging
Powered by Sony’s IMX415 8-megapixel sensor, the MC800S captures vivid, detailed color video down to 0.001 lux – eliminating the need for traditional IR-only night vision. Ideal for 24/7 surveillance in environments where color accuracy is critical.
Dual-Light Source Technology
Integrated support for both infrared (IR) and warm white light via PWM/CDS control. Automatically switches between full-color, IR-only, and dual-light modes based on ambient conditions – enhancing scene visibility while deterring intruders with visible illumination.
Built-in AI Intelligence (1 TOPS)
Onboard 1 TOPS computing power enables real-time human detection, customizable alarm zones, and third-party algorithm integration. Significantly reduces false alarms so you can focus on what matters.
Advanced Video & Audio Capabilities
- H.265+ / H.265 / H.264 encoding with adjustable bitrate (0.1–12 Mbps) and frame rate (1–20 FPS)
- Main stream: 4K UHD @ 20fps (3840×2160); multiple sub-stream options (D1, VGA, 720×480, etc.)
- Two-way voice intercom with G.711 audio codec and AV sync
- Supports OSD character overlay, image flip, and HDR
Seamless Integration & Protocols
- Compatible with ONVIF, RTSP, HTTP, DHCP, NTP, and P2P
- Optional support for GB28181, RTMP, and NVR docking
- SDK provided for Windows, Linux, and Android – accelerate your custom development
Robust Industrial Design
| Parameter | Specification |
|---|---|
| Operating Temperature | -40°C to +85°C |
| Lightning Protection | GB/T17626.5 & IEC61000-4-5 compliant |
| POE | Ready via external adapter |
| Power Input | DC 12V / 170mA |
Smart Control & Monitoring
- Auto/manual/timer-controlled IRCUT switching
- Mobile monitoring via Danale app (iOS & Android)
- IP address filtering for enhanced network security
Technical Specifications
| Parameter | Details |
|---|---|
| Model | MC800S |
| Main Chip | SSC338Q |
| Image Sensor | Sony IMX415, 1/2.8″, 8MP CMOS |
| Max Resolution | 3840×2160 @ 20fps (Main Stream) |
| Video Encoding | H.265+, H.265, H.264 |
| Bitrate | 0.1–12 Mbps (adjustable) |
| Frame Rate | 1–20 FPS (configurable) |
| Night Vision Modes | Full-color + IR + Dual-light |
| Light Control | PWM & CDS signals |
| Network Interface | RJ45, 10/100M Ethernet |
| Audio | G.711, two-way intercom, linear I/O |
| Protocols | ONVIF, RTSP, HTTP, DHCP, NTP, P2P (GB28181 optional) |
| Power Supply | DC 12V / 170mA |
| Operating Temp | -40°C to +85°C |
| Dimensions | 38mm × 38mm |
| SDK Support | Windows, Linux, Android |
Typical Applications
- Smart home & commercial security systems
- Industrial automation & machine vision
- Smart city & traffic monitoring
- Remote site surveillance (oil fields, farms, warehouses)
- AI-powered retail analytics & people counting
Why Choose the MC800S?
| Benefit | Description |
|---|---|
| True 24/7 Color Vision | No more black-and-white night footage |
| AI at the Edge | Process data locally – reduce bandwidth and cloud costs |
| Plug-and-Play Ready | Works seamlessly with most NVRs and VMS platforms |
| Global Compliance | Designed for worldwide deployment |
| OEM/ODM Friendly | Custom firmware, branding, and packaging available |
