The Joyllon WiFi Camera Module is a state-of-the-art, feature-rich embedded vision solution designed for developers and manufacturers seeking high-definition video recording, audio integration, and flexible wireless connectivity. Backed by over a decade of expertise in camera module R&D, Joyllon delivers enterprise-grade reliability tailored for smart security, consumer electronics, industrial automation, and IoT applications.
Key Technical Specifications
| Feature / Parameter | Specification Details |
| Effective Pixels | 1920 × 1080 (Full HD) |
| Lens Size | 1/2.9 inch |
| Frame Rate | 30 FPS |
| Field of View (FOV) | 150° Wide Angle |
| Data Format | YUV / MJPG |
| Operating Voltage | 5V (Supports rechargeable battery integration) |
| Audio Capabilities | Built-in microphone and speaker for voice & video recording |
| Storage Extension | TF card slot for local storage |
| Protocols Supported | TCP/IP, DHCP, HTTP, HTTPS, NTP, DNS, RTP, RTSP |
| System Compatibility | Windows, Linux, Android, OS |
| Interfaces | WiFi & Network Port |
| Dimensions | 35mm × 35mm compact footprint |
| Storage Temperature | -20°C to 80°C |
Core Advantages & Features
- Comprehensive Protocol & SDK Support: Fully compatible with standard networking protocols (RTSP, RTP, HTTP, HTTPS, etc.) and offers SDK secondary development support, allowing seamless integration into custom firmware and software ecosystems.
- All-in-One Audio & Video: Features an integrated microphone and speaker setup, enabling complete audio-visual recording out-of-the-box.
- Flexible Power Options: Engineered to support standard 5V operation alongside rechargeable battery configurations for portable or wire-free deployments.
- Wide-Angle High-Definition Optics: Captures crisp 1080p video at 30 frames per second through a wide 150-degree field of view, ideal for comprehensive spatial monitoring.
About Joyllon
Headquartered in Guangdong—the global manufacturing hub—Joyllon is a technology-driven national high-tech enterprise with over 10 years of deep specialization in the research, development, production, and sales of advanced camera modules. Anchored in core competencies like CMOS image sensing technology and optical system design, Joyllon provides high-precision, high-performance visual solutions across diverse industries:
- Smart Security & Consumer Electronics: Empowering smart monitoring systems, drones, smart robots, and connected consumer terminals with sharp dynamic tracking and environmental awareness.
- Industrial & Medical Solutions: Supplying robust industrial endoscope modules built for harsh environments, as well as ultra-high-definition medical endoscope modules designed for precision imaging.
Discover how Joyllon can elevate your next vision-based product by visiting www.joyllon.com.
Are you looking to integrate this module into a specific project, such as a smart security device or a custom IoT application?
