In modern industrial maintenance, HVAC diagnostics, and electrical inspections, precision and portability are paramount. The YXW256 Wireless Thermal Camera is a cutting-edge, versatile infrared imaging solution designed to transform your smartphone into a powerful diagnostic tool. Blending a high-resolution thermal detector with wireless streaming capabilities, this device is built for engineers, home inspectors, and technicians who demand efficiency and accuracy on the go.
Explore more premium industrial solutions at Joyllon.
Key Features & Product Highlights
- High-Resolution Infrared Imaging: Equipped with a 256×192 IR resolution and a fast 25Hz frame rate, the YXW256 delivers smooth, crystal-clear thermal videos and images without lag.
- Wide Temperature Measurement Range: Reliably detects temperatures spanning from -20°C to 550°C (-4°F to 1022°F), making it perfect for both low-temperature HVAC leak detection and high-temperature industrial furnace inspections.
- Wireless Screen Sharing & Collaboration: Featuring advanced wireless connectivity, the camera allows multiple devices to sync and view the live feed simultaneously. Share real-time monitoring data seamlessly with your team for highly efficient collaborative troubleshooting.
- Dual-Light Fusion & Multiple Image Modes: Choose between 4 distinct viewing modes—Infrared, Visible Light (2MP camera), Picture-in-Picture, and Dual-Light Fusion—alongside 6 adjustable color palettes (White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion) for optimal contrast.
- Intelligent Temperature Analysis: Supports point, line, and area (rectangle) analysis targets. Track maximum, minimum, and center temperatures in real-time, accompanied by instant icon/sound alarms for critical temperature thresholds.
Technical Specifications
| Parameter | Specifications |
| Model | YXW256 |
| Infrared Resolution | 256 × 192 pixels |
| Temperature Range | -20°C ~ 550°C (3 units switchable: °C / °F / K) |
| Accuracy | ±2°C or ±2% of reading (whichever is greater) |
| Thermal Sensitivity (NETD) | ≤40mK @25°C, F#1.0 |
| Detector Type | Vanadium Oxide (VOx) Uncooled Microbolometer |
| Pixel Pitch / Focal Length | 12μm / 3.5mm |
| Field of View (FOV) | 50° × 37.2° (Focus-free) |
| Visible Light Camera | 2.0 Megapixels |
| Battery Life & Charging | 1100mAh Li-polymer |
| OS Compatibility | Android 7.0+ / iOS 12.0+ |
| IP Rating & Certification | IP54 |
| Dimensions & Weight | 41 × 21.55 × 136.6 mm |
Core Applications
The versatility of the YXW256 makes it an indispensable asset across various industries:
- Electrical & Power System Audits: Identify overloaded circuit breakers, loose connections, and hot spots in electrical panels before catastrophic failure occurs.
- HVAC & Building Diagnostics: Locate hidden water leaks, missing insulation, air-conditioning gaps, and underfloor heating blockages without destructive testing.
- Automotive Repair: Inspect brake systems, exhaust manifolds, heated seats, and engine cooling efficiency quickly.
- New Energy & Solar Panel Inspections: Pinpoint defective photovoltaic cells or battery cells overheating in electric vehicles.
- Search & Rescue & Firefighting: Detect heat signatures in low-visibility environments or navigate post-fire cleanup safely.
Frequently Asked Questions (FAQs)
1. How does the wireless multi-connection feature benefit team operations?
The YXW256 supports one-to-many wireless streaming. A technician handling the camera inside a confined or hazardous environment can stream the real-time thermal matrix directly to supervisors or clients sitting outside, significantly increasing safety and collaborative decision-making speeds.
2. Can the YXW256 record video footage for reporting?
Yes. The camera supports high-definition image capture (JPEG) and video recording (MP4), allowing inspectors to save complete visual evidence of thermal anomalies to generate comprehensive maintenance reports via the dedicated mobile application.
3. Is the device rugged enough for industrial field-work?
Absolutely. With an IP54 rating, it is protected against dust ingress and splashing water from any direction, ensuring durability in harsh construction, industrial, and outdoor weather environments.
